Code: LC031
Features
Features (All Models)
-Upright stainless steel collector coil capable of holding 6L of ice before defrosting. Stainless steel collector lid, 3/4″ thick, has neoprene gasket.
-Console cabinet with interior space for vacuum pump (sold separately) and two-piece, removable front panel with viewing window.
-Clear acrylic chamber lid, 3/4″ thick, with neoprene gasket.
-FreeZone Stoppering Tray Dryer.
-Brushed stainless steel and glacier white, powder-coated steel exterior with blue accents.
-Full color, 5″ capacitive touchscreen with Lyo-Works™ OS:
-Real time display of collector temperature, vacuum level, and optional End-Zone™ end point detection system.
-Start–up mode for collector cool-down and vacuum pull-down (automatic or manual).
-Operating mode (standby or run).
-Vacuum set point, alerts, diagnostic tests, user manual, defrost control, and optional drying accessory parameters.
-Data logging stores and displays data in table or chart format, and may be exported via USB or Ethernet.
-Settings include language (English, Spanish, French, German, or Italian), time, time zone, temperature (° C or ° F), and vacuum (mBar, Torr, or Pa).
-Alerts are programmable to send via Ethernet connection to user-entered email addresses.
-Display settings include brightness, touch sounds (on/off), and screen time out in minutes (on/off).
-Maintenance alert settings include vacuum pump oil change, refrigeration cleaning, total operating hours and line voltage offset.
-Level-specific security lock-out prevents changes to programs and other system parameters.
-Hot gas defrost with auto shut off at +60° C (+140° F).
-On/standby switch.
-Moisture sensor that prevents refrigeration or vacuum start-up when moisture is detected in the drain line.
-Vacuum control valve that maintains vacuum level set point.
-Vacuum break valve that bleeds air into the system when power to the freeze dryer or vacuum pump is shut off. If a power outage less than approximately 5 minutes occurs, the freeze dryer will restart and the refrigeration and vacuum system will resume operation once power is restored. If the power failure is more than approximately 5 minutes and the collector warms above safe limits, the freeze dryer will not automatically restart.
-Side-mounted USB port and rear-mounted Ethernet connection.
-Front-mounted, quick-disconnect drain hose fitting and side-mounted lanyard with hose connector. 18″, 1/4″ ID silicone tubing and clamp included.
-Internal electrical receptacle for vacuum pump connection.
-3-wire electrical cord with plug.
-3/4″ OD vacuum connection, 36″ of 3/4″ ID vacuum hose and two clamps.
Options Include
PTFE-coated collector coil and chamber for processing involving corrosive compounds.
Purge valve for isolating the vacuum pump from the freeze dryer.
Region-specific electrical plug configurations.
Required Accessories (Not Included)
Vacuum pump with a displacement of at least 163 L/min, 0.02 mBar ultimate pressure and fitting suitable for 3/4″ ID vacuum hose.
Freeze dry glassware if not bulk freeze drying.
